3M BBI6ARD20' Heat Shrink Tubing - Orange / Red - 20 ft - 35732

051135-35732

The 3M orange / red polyolefin heat shrink tubing is sold 20 ft per case and is another quality product from 3M. This product is made of polyolefin for performance and durability. Has a dielectric strength of 550 v/mil. This product starts out with an inner diameter of 12.858 in and after heat is applied it reduces in size to 7.571 in. Along with other changes the wall thickness also changes when this product is used. Before use the wall thickness is 0.046 in but after it is 0.117 in. The overall length measures 20 ft. This heat shrink tubing meets the following standards: ANSI/IEEE C 37.20, ASTM D 149, ASTM D 150, ASTM D 2303, ASTM D 257, IEC 216.

View technical details

Product Specifications

  • Brand:
    3M
  • 3M Number:
    BBI6ARD20'
  • Material:
    Polyolefin
  • Shrink Ratio:
    1.5 : 1
  • Inner Diameter Before Shrinking:
    12.858 in
  • Inner Diameter After Shrinking:
    7.571 in
  • Wall Thickness After Shrinking:
    0.117 in
  • Wall Thickness Before Shrinking:
    0.046 in
  • Overall Length:
    20 ft
  • Dielectric Strength:
    550 V/mil
  • Color:
    Orange / Red
  • Shrink Temperature:
    +250 °F
  • Maximum Operating Temperature:
    +230 °F
  • Standards Met:
    ANSI/IEEE C 37.20 ASTM D 149 ASTM D 150 ASTM D 2303 ASTM D 257 IEC 216
  • Package Quantity:
    20 ft per case
  • Kit Type:
    7.571
