3M FP-301 Heat Shrink Thin-Wall Tubing - White - 50 ft - 35593
051135-35593
The 3M white polyolefin heat shrink thin-wall tubing is another quality product from 3M. This sku is made of polyolefin for performance and durability. Has a dielectric strength of 900 v/mil. This product starts out with an inner diameter of 0.75 in and after heat is applied it reduces in size to 0.375 in. Along with other changes the wall thickness also changes when this product is used. After use the wall thickness is 0.03 in. The overall length measures 50 ft. This heat shrink thin-wall tubing meets the following standards: AMS 3636, AMS 3637, AMS DTL-23053/5 Class 1, AMS DTL-23053/5 Class 2, CSA LR38227, UL E39100.
Product Specifications
- Brand:3M
- 3M Number:FP-301
- Material:Polyolefin
- Shrink Ratio:2:1
- Inner Diameter Before Shrinking:0.75 in
- Inner Diameter After Shrinking:0.375 in
- Wall Thickness After Shrinking:0.03 in
- Overall Length:50 ft
- Dielectric Strength:900 V/mil
- Color:White
- Shrink Temperature:+212 °F
- Maximum Operating Temperature:+275 °F
- Standards Met:AMS 3636; AMS 3637; AMS DTL-23053/5 Class 1; AMS DTL-23053/5 Class 2; CSA LR38227; UL E39100
