3M Scotchlok MU10-8FFBK Yellow Non-Locking Butted Non-Insulated Butted Fork & Spade Terminal - 0.73 in Length - 0.32 in Wide - 0.32 in Fork Width - 0.135 in Inside Diameter - #8 Stud - 02024
054007-02024
The 3M Scotchlok yellow non-locking butted non-insulated butted fork & spade terminal is sold 500 per case and is another quality product from 3M. Keep in mind this is a "butted" barrel length. The barrel itself is 0.25 in long. Can be used with conductor legs with a minimum diameter of 12 awg. Supported wire sizes are 12 awg to 10 awg. The overall length and width are 0.73 in x 0.32 in.
Product Specifications
- Brand:3M
- Trade Name:Scotchlok
- 3M Number:MU10-8FFBK
- Fastening Mechanism:Non-Locking
- Seam Type:Butted
- Maximum Wire Size:10 AWG
- Minimum Wire Size:12 AWG
- Stud Size:#8
- Color:Yellow
- Insulation Material:Non-Insulated
- Fork Width:0.32 in
- Clearance:0.29 in
- Overall Length:0.73 in
- Package Quantity:100 per bottle, 500 per case
- Barrel Length:0.25 in
- Barrel Length Type:Butted
- Inside Diameter:0.135 in
- Minimum Conductor Leg Diameter:12 AWG
- Overall Width:0.32 in
