Bassett 60° Combined Drill & Countersink B53431 - #1 - Carbide - 2 Flute - 0.125 in Straight Shank
662355-34063
The Bassett combined drill & countersink is easy to use. This part has a 3/64 in diameter and #1 thread. Designed for right hand cut applications. To ensure compatibility with your tool, this part has a 0.125 in straight shank. The combined drill & countersink has a 118° point for hole making applications. This combined drill & countersink is best used in spotting & centering applications. This combined drill & countersink is made of carbide with a bright finish. The overall length measures 1.5 in. This SKU has a 0.125 in body diameter. Has a 4-Facet point.
WARNING:
This product can contains Cobalt and/or Nickel and/or Lead, a chemical known to the State of California to cause cancer or birth defects or other reproductive harm.
For more information: www.P65Warnings.ca.gov
Product Specifications
- Brand:Bassett
- Application:Spotting & Centering
- Material:Carbide
- Surface Finish:Bright
- Hand of Cut:Right Hand Cut
- Overall Length:1.5 in
- Product Type:Combined Drill & Countersink
- Diameter:3/64 in
- Number of Flutes:2
- Thread Size:#1
- Shank Size:0.125 in
- Countersink Angle:60°
- Center Drill Diameter:0.0469 in
- Center Drill Length:0.0469 in
- Case Quantity:1 per case
- Shank Configuration:Straight
- Body Diameter:0.125 in
- Point Angle:118°
- Point Style:4-Facet
